Propriétés techniques
|
Max. Input Level
|
 |
@ -8 dB gain, + 21.8 dBu
@ 0 dB gain, + 14.8 dBu @ 12 dB gain, + 2.8 dBu |
|
||
|
Input Impedance
|
|
20 KOhm, electronically balanced
|
|
||
|
Input Gain
|
|
+/-12 dB
|
|
||
|
Input CMRR
|
|
DC – 1 KHz, > 60´
1 KHz – 20 KHz, > 40 dB |
|
||
|
Max. Output Level
|
|
+20,8 dBu
|
|
||
|
Output Signal Balance
|
|
> 40 dB @ 1 KHz (BBC method)
|
|
||
|
Output Impedance
|
|
100 Ohm, electronically balanced
|
|
||
|
Output Gain
|
|
-18 dB to + 12 dB
|
|
||
|
Frequency Response
|
|
10-22 KHz, +0 -1 dB, Fs=48.0KHz
|
|
||
|
THD
|
|
< 0.01% @ 1 KHz, + 10 dBu
|
|
||
|
IMD
|
|
< 0.01% @ 1 KHz, + 10 dBu
|
|
||
|
Dynamic Range
|
|
> 100 dB (ADA-2)
> 98 dB (ADA-1) |
|
||
|
Crosstalk
|
|
< -80 dB @ 1 KHz
|
|
||
|
Group Delay Linearity
|
|
< 5 µS
|
|
||
|
Phase Linearity
|
|
Better than 5
|
|
||
|
A to D Conversion
|
|
Delta Sigma 20 bit 64x oversampling
18bit (ADA-1) 64x oversampling 18bit (ADA-1) 64x oversampling |
|
||
|
D to A Conversion
|
|
Linear 20bit 8x oversampling
|
|
||
|
Sampling Rate
|
|
48.0 KHz, 44.1 KHz, 32.0 KHz
|
|
||
|
Environment
|
|
Operating, 0° C to +50° C
Storage, -20° C to +60° |
|
||
|
Power Requirements
|
|
Selectable 100/120/220/240V
50-60Hz, 20 to 50 watts 50-60Hz, 20 to 50 watts |
|
||
|
Dimensions
|
|
3 1/2 x 19 x 12 inches
|
|
||
|
Finish
|
|
Black anodized aluminum face plate
Painted and plated steel chassis |
|
||
|
Net Weight
|
|
19 lbs. (8.6kg)
|
