TASCAM 01U Pro

Propriétés techniques

Type Compact Disc player Discs 8 or 12cm (3.1 to 4.7inch) CD, CD-R/CD-RW Formats Audio CD (CD-DA), MP3 Number of channels 2-channel Resolution 16-bit Sampling frequency 44.1kHz Analog line outputs Connectors RCA Maximum Output level +6 dBV dBu Output impedance 1kØ Analog line outputs (CD-01U PRO only) Connectors XLR-3-32 (1:GND, 2:HOT, 3:COLD) Maximum Output level +20 dBu Output impedance 150Ø Headphones Connectors standard stereo jack Maximum Output level 20 mW + 20 mW Load impedance 32Ø Digital input (Coaxial) Connectors Optical Format IEC60958-3 (S/PDIF) Digital output (AES/EBU, CD-01U PRO only) Connector XLR-3-32 Format IEC60958-4 (AES/EBU) Frequency response 20Hz to 20kHz +0.5/- 1.0dB S/N ratio > 95dB (20kHz LPF A-WTD) Dynamic range > 98dB (20kHz LPF A-WTD) Total harmonic distortion < 0.01% (200Hz HPF, 20kHz LPF) Channel separation > 90 dB (at 1 kHz) Wow and flutter Below measurable limits (less than 0.001%) Voltage requirements USA/CANADA 120 CVAC, 60 Hz U.K./Europe 230 VAC,50HZ Australia 240 VAC,50Hz Power consumption 9 W (CD-01U) 11 W (CD-01U PRO) Dimensions 482.6 x 50 x 333.9 mm 19 x 2 x 13.1 (in) Weight 3.5 kg (7.7 lbs)(CD-01U) 3.7 kg (8.1 lbs)(CD-01U Pro) Operating temperature range 5 to 40 degrees C (41∞ F to 104∞ F)
