PROLIGHTS – DOTQ (kit de 6)

95,00€ HT/JOUR

DOTQ – Kit de 6 projecteurs

DOTQ is an ultra-compact, wireless, battery LED accent luminaire designed to light up the entirety of the inside or outside of a room. The compact form factor and chrome finish allows it to be used anywhere that needs a ‘little lift’ to finish off the perfect event design.

Even, powerful saturated and pastel colours from single 15W RGBW LED
Chrome finish, ultra-compact size and IP65 rating for incredible versatility
DOTQ-PACK option including ABS flight case containing 6 fixtures, charging station, top hats, magnetic frost filters, IR controller, eye bolts, suction cups and yokes

LIGHT SOURCE

  • Source:
    1×15
    W
    RGBW LED
  • Luminous flux:
    550
    lm
  • Lux:
    710
    lux
    @3m full
  • Source life expectancy:
    >50.000 h
OPTICS

  • Beam angle:
    15
    °
  • Field angle:
    23
    °
  • Additional optics:
    Magnetic Frost filter included for wider diffusion
COLOUR SYSTEM

  • Colour mixing:
    RGBW/FC
  • White presets:
    2800-9000
    K
  • Colour wheel:
    virtual colour wheel with presets
  • Macros:
    built-in white presets
DYNAMIC EFFECTS

  • Static colour mode:
    selection of static colour
  • Manual colour mode:
    manual adjustment of colour
  • Auto mode:
    built-in programs with execution speed adjustment
BODY

  • Hardware on-board:
    Frost, foots, IR, charger, bracket
  • Tilt angle:
    °
    adjustable foot support for tilt regulation (up to 20°)
  • Body:
    sturdy policarbonate body
  • Body colour:
    mirror finishing
CONTROL

  • Protocols:
    W-DMX, RDM
  • DMX channels:
    5 / 9
    channel
  • W-DMX:
    included, wireless solution receiver
  • RDM:
    RDM ready for fixture remote monitor and settings
  • Display:
    3-Chars display
  • IR:
    infrared remote controller for simple control, addressing and settings
ELECTRONICS

  • Dimmer:
    linear 0~100% electronic dimmer
  • Strobe / shutter:
    1-25
    Hz, electronic
  • Operating temperature:
    0° ~ +35°
  • Flicker:
    flicker free operation
ELECTRICAL

  • Power supply:
    100-240V – 50/60Hz
BATTERY

  • Battery:
    11,1
    V
    lithium
  • Estimated battery life in colour change mode up to:
    10
    h
  • Estimated battery life in single colour mode up to:
    15
    h
  • Estimated battery life in full-mode up to:
    5
    h
  • Re-charge connection:
    power cable
  • Re-charge time:
    3
    h/max
  • Battery status:
    LED battery status indicator

Propriétés techniques

  • Cooling:
    natural cooling of the peculiar chassis and to absence of fans
  • Sospension and fixing:
    hanging bracket suitable for safe hanging and positioning
  • IP rating:
    For temporary outdoor use –
    IP65 (front) – IP54 (bottom)
  • Dimensions (WxHxD):
    88x88x63
    mm
  • Weight:
    0.6
    kg
