Propriétés techniques
Threshold
Continuously variable from -20 to 10dBu
Depth
Continuously variable from 0 to 20dBu
Time Constants
Peak Mode:
A: 50mS B: 100mS
C: 200mS
D: 750mS
E: 1.5S
F: 3S
RMS Mode Time Constant data collected using 10dB bursts.
Attack: fixed 20mS
Release:
A: 20mS
B: 200mS
C: 1S
D: 2S
E: 5S
F: 30S
Maximum Output Level:
+25dBu
Total Harmonic Distortion and Noise
Feedback Suppressor Engaged: Main Output
Better than 0.002%
Noise
Feedback Suppressor Engaged: Measured @ Main Output, un-weighted, 22Hz-22kHz, 50 ohm terminated input
Better than -100dBu
Better than -95dBu
Frequency Response
Main Output
@ 20Hz -3dB
@150kHz -3dB
Crosstalk
Measured Channel to Channel
Better than -80dB @ 16kHz
