Propriétés techniques
Audio Input
Level: -20dB or +4dB
Impedance:*-20dB, >50k? unbalanced
******************+4dB, 40k? balanced
Connection: 1/4″ TRS jack
Audio Outputs
Levels: +4dB +10dBV into 600?
******************* +16dBV into >10k?
********** -20dB -8dBV into >10k?
Impedance: 600? unbalanced
Connections: 2 x 1/4″ TRS jacks
Frequency**** Wet: 20Hz-15kHz ±1dB
Response**** Dry: 20Hz-20kHz ±0.25dB
Dynamic Range*** 80dB, 20Hz-20kHz
Total Harmonic*** Wet: 0.07% 1kHz
Distortion*** Dry: <0.025% 1 kHz @ 3V out
***************** Wet: <0.05% 1 kHz @ full out
Encoding*** 16-bit linear PCM
Memory*** 40 permanent presets
*************** 50 user programmable registers
MIDI IN, MIDI THRU/OUT internally selectable
Footswitches: Bypass, Register step (1/4″ jack)
RFI Shielding**** Complies with FCC requirements for Class A computer equipment
Power Requirement: 100/120/220/240V 50/60Hz
Physical: 1u 19″ standard rack mount*x 344mm deep
Weight: 4.9kg (10.7 lbs)
