Propriétés techniques
| Input | (4) total |
| Input Connectors | Female XLR |
| Input Type | Electronically balanced, RF filtered |
| Insert Impedance | >50k ohm |
| Max Input | Software selectable for: +28, +26, +24, +22, +20, +18, +16, +14 dBu |
| CMRR | >40 dB typical, >55 dB at 1 kHz |
| Digital Inputs | (4) AES/EBU Channels |
| Digital Input Connectors | Female XLR |
| Digital Input Type | Transformer Isolated, RF filtered |
| Digital Input Impedance | >110 ohms |
| Mic Preamp Connector | (RTA) – (1) Female XLR |
| Mic Preamp gain | (RTA) 10dB to 50dB in 10dB increments |
| Output | 8 total |
| Output Connectors | Male XLR |
| Output Type | Electronically balanced, RF filtered |
| Output Impedance | 30 ohms |
| Max Output | Software selectable for: +24, +22, +20, +12, +8, +4 dBu |
| Digital Output | (8) AES/EBU Channels |
| Digital Output Connector | Male XLR |
| Digital Output Type | Transformer Isolated, RF filtered |
| Digital Output Impedance | >110 ohms |
| A/D Converter | dbx Typve IV™ Converstion System |
| A/D Dynamic Range | >114 dB unweighted, 116dB A-weighted |
| Type IV Dynamic Range | 128dB with transient material, A-weighted, 22kHz BW 126 dB with transient material, unweighted, 22 kHz BW 120 dB typical with program material, A-weighted, 22 kHz BW |
| Sample Rate | 96kHz |
| Wordlength | 24 bits |
| D/A Dynamic Range | 112 dB unweighted, 115 dB A-weighted |
| Dynamic Range | 112dB unweighted, 115dB A-weighted |
| Internal Processing | 32 bit floating point |
| THD+Noise | 0.004% typical at +4 dBu, 1 kHz, 0 dB input gain |
| Frequency Response | 20 Hz- 40 kHz, +/-0.5 dB |
| Interchannel Crosstalk | <-85 dB at 1 kHz, 0 dB input gain |
| Pre EQ Type | One 31-band Graphic EQ on each input One EQ that is switchable between 31-band and 9-band Parametric on each input |
| EQ Gain | +/- 12dB |
| Input Insert Processing | Two selectable Insert Processing blocks per input: Noise Gate, Compressor, Auto Gain Control, De-Esser, Sub-Harmonic Synth, Advanced Feedback Suppression |
| Input Delay Length | Up to 682 mSec available |
| Routing/Mixing | 4-input mixer available at each output allowing any input to be sent or mixed to any output |
| Output Insert Processing | Two selectable Insert Processing blocks per output: Noise Gate, AutoWarmth®, Compressor, Auto Gain Control, Peak Limiter, Sub-Harmonic Synth, Advanced Feedback Suppression |
| Crossover | configs: 1×1, 1×2, 1×3, 1×4, 1×5, 1×6, 1×7, 1×8, 2×2, 2×3, 2×4 2×5, 2×6, 2×7, 2×8, 3×3, 3×4, 3×6, 3×7, 4×4, 4×5, 4×8 |
| Crossover Filter Type | Bessel 6, 12, 18, and 24 dB per Octave Butterworth 6, 12, 18, and 24 dB per Octave Linkwitz-Riley 12, 24, 36, and 48 dB per Octave |
| Polarity | Positive and Negative |
| Phase Control | 0 to -180 degrees in 5 degree increments |
| Output Delay Length | 1365 mSec shared between the outputs |
| Transformer | I/O: optional |
| Controls | Ethernet, RS-232, Optional dbx ZC Wall Panels |
| Power Consumption | 100V to 240V 50/60Hz, 45 Watts |
| Dimensions | 3.5″x19″x12.15″ |
| 设备重量 | 11 lbs. |
| Shipping Weight | 12.5 lbs. |
