Propriétés techniques
span class= »textrouge10capital »>INPUT Impedance Balanced 12kOhm differential
Headroom +20dBv.
CMRR Better Than-50dB, 20Hz to 20kHz
INPUT Connector XLR3-31 or equivalent
OUPUT Impedance Balanced and floating to drive 600 Ohm loads.
OUPUT Level +20dBv into 600Ohm load
OUPUT Connector XLR3-32 or equivalent
Frequency Response + 0.5dB, 20Hz to 20kHz, all sections bypassed
Noise Measured to CCIR 468-2. Less than -90dBv, all controls set flat
Distortion THD Less than 0.05%, 20Hz to 20kHz, SMPTE IM Less than 0.02%
Threshold Variable each band from +20dBv to -30dBv
Comp/Exp Variable each band from -30dB compression to +16dB expansion. Soft knee at low settings
