Propriétés techniques
ELEMENT
Fixed-charge back plate, permanently polarized condenser
POLAR PATTERN
Cardioid
FREQUENCY RESPONSE
30-20,000 Hz
OPEN CIRCUIT SENSITIVITY
-33 dB (22.4 mV) re 1V at 1 Pa
IMPEDANCE
200 ohms
MAXIMUM INPUT SOUND LEVEL
130 dB SPL, 1 kHz at 1% T.H.D.
DYNAMIC RANGE (typical)
103 dB, 1 kHz at Max SPL
SIGNAL-TO-NOISE RATIO
67 dB, 1 kHz at 1 Pa
PHANTOM POWER REQUIREMENTS
9-52V DC, 2 mA typical
WEIGHT
14.6 oz (415 g)
DIMENSIONS
4.72″ (120.0 mm) maximum width,
5.71″ (145.0 mm) maximum length,
0.67″ (17.0 mm) height
OUTPUT CONNECTOR
TB3M-type
CABLE
25′ (7.6 m) long, 0.13″ (3.2 mm) diameter, 2-conductor, shielded; with TA3F and XLRM-type connectors
ACCESSORY FURNISHED
Soft protective pouch
