Propriétés techniques
C 414 B-ULS
FREQUENCY RANGE
20 Hz to 20 kHz
POLAR PATTERNS
Cardioid, Hypercardioid, Omnidirectional and Figure-8
PREATTENUATION
-10 dB, -20 dB switchable
BASSCUT FILTER
12 dB/octave roll-off at 75 Hz or 150 Hz
SENSITIVITY
12.5 mV/Pa (-38dBV) (all patterns)
IMPEDANCE
180 ohms
EQUIVALENT NOISE LEVEL
14 dB-A
MAXIMUM SPL FOR 0.5% THD
140 dB (160 dB@-20 dB) at 1 kHz
134dB (154dB@-20dB) 30Hz-20kHz
POWER REQUIREMENT
9-52 V phantom power to DIN 45596
CURRENT CONSUMPTION
approx. 2 mA
SIZE
141x45x35 mm (5.6×1.8×1.4 in.)
NET/SHIPPING WEIGHT
320/920 g (11.3 oz. /2.1 lbs.)
